RJ45 5921 ; 2X2 ports ; Without LED ; With metal shield(EMI Fingers) . PCB Retaining Post: hollow(Type B)
Number of views:
1000

RJ45 5921 ; 2X2 ports ; Without LED ; With metal shield(EMI Fingers) . PCB Retaining Post: hollow(Type B)

Connector type:
RJ45 5921
Number of Ports:
2X2 ports
Clamp direction:
Integrated transformer:
No.
Turns Ratio RX:
No.
Main electrical parameters:
Open/Short test pass.
LED option:
No.
Contact Mating Area Plating:
Gold G/F / 0.8u''/ 1u''/ 1.5u''/ 3u''/ 6u''/ 15u''/ 30u''/ 50u''
Shield EMI Tabs:
Yes.
Working temperature:
0 - 85 degree Celsius or -40 - 85 degree Celsius.
Storage temperature:
-40 - 85 degree Celsius
Suitable for welding type :
Wave-soldering(Normal) or Reflowsolding(Alternative).
Product standard:
Meets IEEE 802.3 specification.
RoHS Compliant:
Yes.
REACH Compliant:
Yes.
Quality as surance:
Electrical performance 200% test passed.
Packing specification:
Technical advisory work:
Email to gc@dgkyd.com or kyd@dgkyd.com.
Notes:
Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
753
Quantity
-
+
Stock:
0
1
介绍:
Download instructions:

01:DGKYD59212288HWA1DY4A

Members 'Notes:

If you want to download the product engineering drawings, please login to become a member and upgrade from DGKYD to advanced member to obtain the download permission, or contact gc@dgkyd.com directly to obtain the drawings.

Product description
Parameters





















Keyword:
RJ45
2X2
DIP
Without transformer
With shield
